Chain Crusher

The video could not be loaded.

Overview
Chain fertilizer is suitable for te fragmentation of organic fertilizer and compound fertilizer blocks during production process,it also widely used in chemical,building materials,mining and other industries.In the process of crushing,we use synchronous speed of high-strength wear-resistant carbide chain plate,inlet and outlet design is reasonable,so that broken material uniformly,uneasy to stick wall and easy to clean.This type crusher using the latest technology and high-quality steel,system optimization design,so it is of large yield and high reliability.

Advantages of the chain crusher:
The chain crusher has the advantage of reasonable structure,fast feeding,stable performance and strong shack resistance.The machine suitable for crushing raw materials and recycled materials,and it is also widely used in chemical industry,building materials,mining and other industries.No matter solft objects or hard objects will not affect the crushing effect.

.
The function and structure
There are two types structure: one is vertical type with single motor, the other is horizontal type with double motor. The main working parts of Chain crusher is the rotor with steel chain, the steel chain connected to the rotor at one end, and connected the chain head with Wear resistant steel material. Chain crusher belong to impact crusher by high speed rotating chain to crushing the materials. Double rotor structure of horizontal chain crusher has its own drive motor rotor shaft, and the circumference speed of Chain head within the scope of the 28 ~ 78 m/s. Horizontal chain crusher is consist of feed inlet, engine body, outlet, rotor with bearing, gearing and reducer. There were liner panel sticking to the engine body in case of the friction between materials and engine body. In addition, it equipped with maintenance window easy access.The engine body and gearing were installed on the pedestal, and the shock absorber is involved with base under the pedestal
Model Maximum size of entering graule (mm) Size after crushing Motor power Prod capacity
LP500 ≤60 <Φ0.7 11 1-3
LP600 ≤60 <Φ0.7 15 1-5
LP800 ≤60 <Φ0.7 15 2-8
